£4,800.00*
£45.99
- Resolution 3840 x 2160 4K UHD
- Max. Brightness 450 cd/m²
- Panel type IPS
- Contrast Ratio 1,200 :1

Product information
The 86-inch Interactive Display WAFX-P: EDLA-certified for seamless collaboration
As a certified AV media consultant at visunext, we recommend Samsung's Interactive Display WAFX-P if you are looking for a future-proof and powerful solution for hybrid learning and working environments. This 86-inch touchscreen display is more than just an interactive whiteboard; it is a central collaboration hub specifically designed to solve the typical challenges in the classroom or meeting room. Thanks to the combination of the fast Android™ 15 interface and EDLA certification, you benefit from smooth performance and full access to all Google services.

The advantages of the Samsung WA86FX-P at a glance:
- All-in-one video call system: Conduct remote classes or video conferencing instantly – without additional peripherals.
- EDLA certification: Seamless and secure access to the Google Play Store and all Google apps for an optimised learning and working environment.
- AI Write and Search: Perform quick web searches by simply circling handwritten notes – no tedious typing required.
- Ultimate performance: The fast Android™ 15 platform and a powerful octa-core processor ensure smooth, intuitive operation and multitasking.
Detailed features for superior collaboration
Intelligent collaboration: all-in-one video system and quick notes
A common problem in hybrid environments is the complicated setup of video conferencing. The WAFX-P Interactive Display solves this with its fully integrated all-in-one video call system. The built-in 48MP camera with auto-framing keeps the speaker in focus at all times, while the powerful microphone clearly captures voices from up to 10 metres away. This allows teachers and business users to start remote collaboration without delay and without having to connect external cameras. Coupled with Fast & Precise Writing technology, the display offers a lag-free, paper-like writing experience. Even the fast Annotation On feature allows you to take notes directly on the screen at any time without having to interrupt the current session. This smooth interplay of visual and audio transmission and easy note-taking creates a superior overall experience in any classroom or meeting situation.

Maximum workflow with Android™ 15 and EDLA standard
To ensure truly intuitive and fast use, the WAFX-P relies on a combination of Android™ 15 and an octa-core CPU. This architecture guarantees smooth performance that effortlessly handles even demanding multitasking scenarios. The decisive advantage, especially for educational institutions, is EDLA certification. This ensures that the display can seamlessly access all Google apps and services and delivers an optimised learning and collaboration experience. This allows teachers to use their familiar tools and students to access relevant content immediately. In addition, the clever AI Write & Search function uniquely accelerates your workflow. Simply highlight handwritten notes on the screen and tap the search icon to instantly retrieve web content, images and more – saving a huge amount of time in class or during spontaneous brainstorming sessions.

Easy connectivity and centralised management with DMS
Complex cable clutter and cumbersome connections are a thing of the past. The 3-in-1 USB-C port supports touch control, screen connection and charging your device (up to 65W) with just a single cable. This not only simplifies setup, but also increases the longevity of your hardware. For educational institutions or large enterprises , the WAFX-P also offers a proprietary Device Management System (DMS) that enables centralised management of all displays. This ensures stable and efficient operation across the entire campus, including the ability to send instant announcements or emergency messages to all devices. For users who prefer their familiar Windows operating system, a full-featured Windows PC can also be integrated via the OPS slot.
Our conclusion: Why the WAFX-P interactive display is the ideal choice for your classroom or meeting room
The Interactive Display WAFX-P sets a new standard for interactive screens. It combines the smooth performance of Android™ 15 with the central user-friendliness of EDLA certification and, thanks to the all-in-one video call system, delivers an unrivalled solution for hybrid scenarios. With its integrated device management system, it also offers a clear competitive advantage in terms of administration and security. The WAFX-P is the perfect investment for a long-lasting and future-proof solution. We accompany you every step of the way: from initial consultation to media technology planning, visunext is your one-stop shop for all you need.
Technical data
| Name | Samsung WA86FX-P 86" Interactive Display with All-in-One Video Call System |
|---|---|
| Article number | 1000037143 |
| GTIN/EAN | 8806097620242 |
| Manufacturer SKU | LH86WAFPLGCXEN |
| Model name | WA86FX-P |
| Brand | Samsung |
| Product Type | Touch display |
| Product Series | Samsung WAF Series |
| Technology | LCD |
| Panel type | IPS |
| backlight | LED |
| Resolution | 3840 x 2160 4K UHD |
| Diagonal | 86" |
| Aspect Ratio | 16:9 |
| Viewing angle - Horizontal | 178° |
| Viewing angle - Vertical | 178° |
| Contrast Ratio | 1,200 :1 |
| Max. Brightness | 450 cd/m² |
| run-time | 12/7 |
| Response time | 8ms |
| Refresh Rate | 60Hz |
| Support - VESA | 800 x 600 |
| Frame width | 14.9 mm |
| Operating system | Android |
| Inputs | 1x 3,5mm Jack , 1x Displayport , 1x Ethernet , 1x RS232 , 2x HDMI , 4x USB-A |
| Outputs | 1x 3,5mm Jack , 1x Ethernet |
| wireless technology | Bluetooth , WiFi |
| Features | Camera integrated , Integrated speaker , Touch screen |
| Product width | 195.04 cm |
| Product height | 117.4 cm |
| Product depth | 8.71 cm |
| Weight | 60.9 kg |
| Colour | Black |
| EEK Spectrum | A to G |
| Condition | New |
| Warranty | 24 Month |
| Warranty type | Onsite Repair Service and support information |
