Crestron DM-NVX-360 DM NVX® 4K60 4:4:4 HDR Network AV Encoder/Decoder

The DM-NVX-360 is a high-performance AV-over-IP encoder/decoder ideal for demanding network AV installations in corporate, educational, and large campus environments. With the ability to transmit 4K60 4:4:4 video in real time over standard Gigabit Ethernet, the DM-NVX-360 combines the highest image quality with versatile features and broad compatibility.

The technical data at a glance:

• 4K60 4:4:4 video transmission over Gigabit Ethernet
• HDR10, HDR10+ and Dolby Vision® support
• Pixel Perfect Processing technology for lossless video quality
• HDCP 2.3 compliant
• Configurable as encoder or decoder
• One HDMI® input and one HDMI output with 4K60 4:4:4 scaler
• Video Wall processing for up to 64 displays
• Dynamic text overlay and image preview
• Analogue audio embedding or de-embedding
• 7.1 surround sound support
• AES67 audio embedding and de-embedding
• USB 2.0 and KVM signal transmission
• Copper and Fibre Ethernet connection
• Automatic point-to-point connectivity
• Device control via RS-232, IR and CEC
• Easy set up via integrated web pages
• Compact surface-mount design
• Power over POE+ or optional power supply

Perfect 4K video transmission

With the DM NVX technology of the DM-NVX-360, you can experience seamless 4K60 4:4:4 video transmission in real time. This technology is optimised for demanding applications such as conference rooms and classrooms and ensures smooth, interactive functionality. Thanks to support for HDR and HDCP 2.3, modern media content is displayed in the highest quality.

Versatility through encoder/decoder functionality

The DM-NVX-360 can be flexibly configured as an encoder or decoder, making it a versatile and cost-effective solution for any AV installation. This feature makes it possible to transmit HDMI signals over the network or to forward received signals to a display. Switching between modes takes less than a minute.

Video Wall and dynamic text overlay

Thanks to the integrated video wall functionality, up to 64 displays can be seamlessly connected. In addition, the DM-NVX-360 offers the option of displaying dynamic text on the screen to display information such as announcements or warnings in real time.

Easy to set up and manage

The DM-NVX-360 can be conveniently set up via a web browser. Management and configuration are further simplified by support for DM NVX Director virtual switching appliances. All ports and LED indicators are easily accessible, allowing for simple and clean installation.

Maximum security and compatibility

The DM-NVX-360 offers comprehensive security features, including 802.1X authentication and AES-128 encryption, that meet the most demanding IT guidelines. Compatibility with existing networks and support for AES67 for audio streaming make the DM-NVX-360 the ideal solution for any professional AV environment.

With the DM-NVX-360, you get a future-proof and flexible solution for your AV transmissions in the highest quality. Please refer to the data sheet under "Downloads" for further technical specifications and details.
