£1,652.40*
£8.99
- Light Brightness 4,000 Lumen
 - Resolution 1920 x 1080 Full HD
 - Aspect Ratio 16:9
 - Operating noise 32 dB


Product information
The ViewSonic LSD400HD-ST short throw Laser Installation Projector: Maximum Flexibility with Minimal Maintenance
As leading experts in professional media technology, we recommend the ViewSonic LSD400HD-ST short throw laser installation projector for all environments where limited space meets the highest image requirements. Many integrators and IT administrators face the problem of having to project a large, bright image in small or confined spaces without presenters being disturbed by the projector or shadows. The LSD400HD-ST's 4000-lumens short-throw projector concept solves this problem. Thanks to advanced laser technology, you get a maintenance-free, durable solution that fits seamlessly into any existing AV infrastructure. Get a projection system that combines performance and ease of installation now.
Your advantages at a glance:
- Short throw: Projection of a 100-inch image from a distance of only 1.1 metres, eliminating annoying shadows and glare.
 - Maintenance-free laser projector: Up to 30,000 hours of operation without lamp replacement thanks to 3rd generation laser phosphor technology.
 - High brightness for clear 1080p images: Detailed Full HD resolution with 4,000 ANSI lumens for vivid images in lit rooms.
 - Comprehensive installation flexibility: 360° projection and 4-corner correction for effortless alignment on uneven or unusual surfaces.

Detailed product features and customer benefits
Long-term cost-effectiveness thanks to maintenance-free laser technology
The ViewSonic LSD400HD-ST uses state-of-the-art 3rd generation laser phosphor technology and offers an impressive light source life of up to 30,000 hours in SuperEco mode. For you, this means no lamp changes, no downtime and a massive reduction in total cost of ownership (TCO). In addition, the maintenance-free laser projector ensures maximum reliability thanks to its IP6X-sealed optical engine. This filter-free, dust-proof design prevents particles from entering the inner core of the projector. The result is consistently brilliant image quality throughout its entire service life, without the need for regular cleaning. Put your trust in a solution that is not only powerful, but also designed for maximum cost efficiency and durability.
Brilliant images that impress even in the smallest of spaces
Despite its compact design, the ViewSonic LSD400HD-ST delivers outstanding image performance. Thanks to the short throw lens (0.5 projection ratio), you can produce a large 100-inch image from a distance of just 1.1 metres. This is ideal for small meeting rooms, classrooms or highly flexible applications such as golf simulators. The short distance not only minimises the space required, but also effectively prevents presenters from casting shadows on the projection surface or being dazzled. The combination of 4,000 ANSI lumens brightness and native 1080p Full HD resolution ensures razor-sharp and detailed content. Supported by a high native contrast ratio of 3,000,000:1 thanks to advanced DLP technology, deep blacks and vivid colour transitions are guaranteed. This means that your presentations or teaching content remain clear, bright and impressively visible at all times, even in bright environments.
Installation flexibility and ProAV network control
The ViewSonic LSD400HD-ST has been specially designed for professional installations and offers maximum flexibility. The 360° projection and 90° portrait mode functions open up creative applications, from ceiling projection in retail environments to complex installations in exhibitions. Precise image alignment is a breeze with H/V keystone correction and 4-corner adjustment. Even if the projector has to be mounted at an angle, you can easily achieve a perfectly rectangular and proportional image. For IT administrators, comprehensive ProAV network control via Crestron, AMX, Extron and PJ Link is a decisive advantage. This compatibility enables centralised remote maintenance and monitoring of the projector, which significantly simplifies the management of large installations.
Our conclusion: Why the ViewSonic LSD400HD-ST is the ideal choice for your facility
The ViewSonic LSD400HD-ST is the definitive short-throw laser installation projector if you need maximum performance, maintenance-free operation and flexibility. The 30,000-hour laser lifetime combined with IP6X protection reduces your operating costs in the long term. At the same time, the 0.5 short-throw ratio and 4,000 ANSI lumens solve the problem of cramped, well-lit rooms with brilliant Full HD projection. Do you need individual planning for your classroom or conference room? Trust in the expertise of visunext. We offer you a personal, free consultation. Contact us now for a tailor-made solution!
Technical data
| Name | ViewSonic LSD400HD-ST Short Throw 4,000 ANSI Lumens 1080p Laser Installation Projector |
|---|---|
| Article number | 1000036506 |
| GTIN/EAN | 0766907034301 |
| Manufacturer SKU | LSD400HD-ST |
| Lamp life (ECO) | 3,000 Hour |
| Lens included | Yes |
| Model name | LSD400HD-ST |
| Projection Distance | Short Throw |
| Brand | ViewSonic |
| Product Type | Projector |
| Product Series | ViewSonic LDS Series |
| Application | Business projector , Education projectors , Installation projectors |
| Projector Type | DLP |
| Projector lamp type | Laser |
| ANSI Lumen | 4,000 ANSI Lumen |
| Resolution | 1920 x 1080 Full HD |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 3,000,000 :1 |
| Operating noise | 32 dB |
| Operating noise - ECO | 27 dB |
| Lamp life | 20,000 Hour |
| Minimum Projection Distance | 44 cm |
| Maximum Projection Distance | 329 cm |
| Minimum Projection Ratio | 0.5 |
| Maximum Projection Ratio | 0.5 |
| Horizontal Keystone | 15% |
| Vertical Keystone | 15% |
| Inputs | 1x Ethernet , 1x RS232 , 2x HDMI |
| Outputs | 1x 3,5mm Jack , 1x USB-A |
| Features | 360° projection , Integrated speaker |
| Product width | 28.6 cm |
| Product height | 12.9 cm |
| Product depth | 21.6 cm |
| Weight | 3.1 kg |
| Colour | White |
| Delivery contents | Lens cap , Power cable , Quick user guide , Remote control , warranty card |
| Condition | New |
| Warranty | 36 Month |
| Warranty type | Pickup service  Service and support information  |
